Submarine sediment in situ test platform Voyager II -
Submarine sediment in situ test platform Voyager II
- BrandUnited Kingdom Partrac
- Model
- OriginImport
VoyagerII is currently the world's only in situ test platform for the study of marine and river surface subsurface sediment, which makes up for gaps in situ measurement in sediment research. Compa
VoyagerII is currently the world's only in situ test platform for the study of marine and river surface subsurface sediment, which makes up for gaps in situ measurement in sediment research. Compared with the experimental data obtained from the laboratory sink, the data collected by the Voyager II Sea Flume is the most direct and real field data.
Platform size: diameter 2200mm, height 1100mm, weight 210Kg.
Ring diameter: 200.8cm, inner diameter: 196.2cm, width 150mm, height: 300mm, the internal installation of the gear motor (adjustable speed) and 8 paddles, driving the flow of one-way or reciprocating circulation, The maximum shear force is 3 Pa (3 N m-2).
Standard sensor: point flow meter, turbidity sensor, underwater sediment profile camera, column sample sampler, automatic water harvesting device.
Maximum working depth: 200m.
Optional sensor: CTD, tilt meter, altimeter, electrode method dissolved oxygen sensor.
