Seasurvy MS400 multi - beam depth sounder -
Seasurvy MS400 multi - beam depth sounder
- BrandHaizhu Tongchuang
- ModelSeasurvy MS400
- OriginMade in China
MS400 high-frequency shallow water depth sounding system is the first international first level of multi-beam depth sounder, the inertial sensor and acoustic array to achieve the integration of integr
MS400 high-frequency shallow water depth sounding system is the first international first level of multi-beam depth sounder, the inertial sensor and acoustic array to achieve the integration of integration, greatly reducing the difficulty of using the operation and convenience.
Operating frequency: 400kHz
Number of beams: 512
Parallel, vertical track beam width: 1 °
Beam angle range: 143 ° (adjustable coverage)
Sounding range: 0.2-150m
Depth resolution: 1.5cm
Measurement mode: isometric / equidistant
Maximum Ping rate: 20Hz
Pulse width: 25us-500us
Pressure rating (acoustic probe): 50m
